Hegel · Integrated Amplifiers
H600
The H600 is Hegel's reference stereo amplifier with 2x303W, a damping factor of 4000, and full streaming capability.
fig. 01 · integrated amplifiers
H600
From Hegel
The H600 is the top of Hegel's built-in range. It outputs 2x303W into 8 ohms from a dual-mono design and drives loads down to 2 ohms. The damping factor sits at 4000, which gives it serious grip on difficult speaker loads.
Digital inputs include AES/EBU, coaxial, optical, USB, and network. Streaming covers AirPlay, Spotify Connect, Roon Ready, and UPnP. Analog inputs run through balanced XLR and unbalanced RCA.
At 303W per channel, this is as much power as Hegel puts in a single chassis.
Specifications
| Power output | 2 x 303W in 8 ohms @ 1kHz 1% THD, 100/120/230V AC, Dual Mono |
|---|---|
| Minimum load | 2 ohms |
| Analog inputs | 2 x Balanced (XLR), 2 x Unbalanced (RCA) |
| Digital outputs | 1 x Coaxial (BNC) S/PDIF - 24/192 |
| Digital inputs | 1 x Coaxial (BNC) S/PDIF - 24/192, DSD64 (DoP), MQA 8x, 1 x Coaxial (RCA) S/PDIF - 24/192, DSD64 (DoP), MQA 8x, 3 x Optical S/PDIF - 24/96, MQA 8x, 1 x USB -32/384, DSD256 (DoP), MQA 8x, 1 x Network - 24/192, DSD64, MQA 8x |
| Line level outputs | 1 x Unbalanced fixed (RCA), 1 x Unbalanced variable (RCA) |
| Streaming | Spotify Connect (Lossless), AirPlay, Google Cast, Roon Ready, Qobuz Connect, Tidal Connect, airable Internet Radio and Podcast, UPnP, JPLAY Certified |
| Streaming formats | MP3, WAV, FLAC, ALAC, AIFF, DSF, DFF, AAC, PCM, MQA, Ogg |
| Frequency response | 5Hz-100kHz |
| Signal-to-noise ratio | More than 100dB |
| Crosstalk | Less than -100dB |
| Distortion | Less than 0.005% @ 50W 8 Ohms 1kHz |
| Intermodulation | Less than 0.01% (19kHz + 20kHz) |
| Damping factor | More than 4000 (main power output stage) |
| Dimensions/weight | 17,1cm x 43cm x 44,5cm (HxWxD), 22kg |
| Dimensions/weight US | 6,74" x 16,93" x 17,52" (HxWxD), 48,51 lbs |
