Isotek · Power Conditioning
EVO3 Sigmas
Six-way EVO3 mains conditioner with 2 high-current outlets, 4 medium-current outlets, and voltage/THD display modes.
fig. 01 · power conditioning
EVO3 Sigmas
6 photographs · 5 shown
From Isotek
EVO3 Sigmas has 6 output sockets split between high-current components and source components. The saved specs list 2 high-current outlets, 4 medium-current outlets, a 16A IEC C20 mains inlet, voltage / THD / off display modes, and 108,000A surge protection.
Specifications
| Output sockets | 6 |
|---|---|
| Output socket types | UK, EU, US, AU & CH |
| Display | Voltage / THD / off |
| Mains inlet | 16A IEC C20 |
| Mains voltage | 100-240V / 50-60Hz |
| Medium-current outlets - 230V | x4 (10A 2'300W total) |
| Medium-current outlets - 115V | x4 (10A 1'150W total) |
| High-current outlets - 230V | x2 (16A 3'680W total) |
| High-current outlets - 115V | x2 (16A 1'840W total) |
| Surge protection | 108'000A |
| Dimensions (W x H x D) | 445 x 90 x 305mm |
| Weight | 10Kg |
| Product type | mains power conditioner |
| Series | EVO3 |
