Series 5 System
The Series 5 System pairs a Selekt DSM hub with Series 5 floorstanding speakers, running full Exakt digital crossover with three 100W amps per speaker.
fig. 01 · all-in-one systems
Series 5 System
8 photographs · 5 shown
From Linn
The Series 5 System pairs a Selekt DSM hub, in Classic or Edition styling, with Linn's Series 5 floorstanding speakers. Each speaker runs an Exakt digital crossover with three onboard 100W amplifiers, so the drive units are powered directly rather than through a separate amp.
The hub streams up to 24-bit/384kHz across FLAC, Apple Lossless, WAV, DSD (64/128/256), MP3, WMA, AIFF, AAC, and OGG, with TIDAL, Qobuz, Spotify Connect, Deezer, AirPlay 2, Roon, airable, TuneIn, and Calm Radio built in. A configurable MM/MC phono stage handles turntable input, and Space Optimisation+ manages room correction.
Each Series 5 speaker uses a 19mm silk dome tweeter with an anti-resonant chamber, a 133mm doped two-layer slice midrange, and an Isobarik bass system with two 165mm drivers, loaded into a 30-litre, 232 mm wide, 954 mm tall, 325 mm deep cabinet weighing 30 kg.
Standard Fabrik covers Aubergine, Black, Blueberry, Butterscotch, and Paprika, with a Harris Tweed option in Barley, Granite, Grouse, Peat, or Spruce. The stand and top plate come in black or white, and the Selekt DSM hub in Classic or Edition, black or silver.
Specifications
| Phono Stage | MM/MC (configurable) |
|---|---|
| Surround Compatible | Yes |
| Exakt | Yes |
| Room Correction | Space Optimisation+ |
| Audio Formats | FLAC, Apple Lossless, WAV, DSD (64/128/256), MP3, WMA (except lossless), AIFF, AAC, OGG |
| Resolution | Up to 24-bit 384 kHz |
| Integrated Services | TIDAL, Qobuz, Spotify Connect, Deezer, AirPlay 2, Roon, airable, TuneIn, Calm Radio |
| WiFi | Yes (802.11ac) |
| Bluetooth | Yes (4.2) |
| HDMI Spec | HDMI ARC (HDMI 2.0) supports; 4K @ 60 Hz, HDCP 2;2; HDR |
| Optional HDMI Module Upgrade | x4 HDMI In + x1 HDMI Out (doubles as eARC) |
| Ethernet | x1 |
| Exakt Link | x2 |
| Construction | Folded and machined aluminium |
| HDMI ARC | x1 |
| Toslink | x2 |
| SPDIF | x2 (x1 configurable in/out) |
| USB Audio Class 2 Endpoint | x1 |
| Line Level Phono (RCA) | x1 |
| MM Phono (RCA) | x1 |
| MC Phono (RCA) | x1 |
| HDMI 2.0 (optional upgrade) | x1 |
| SPDIF (configurable in/out) | x1 |
| RCA Subwoofer Out | x1 |
| 1/4" Headphone Jack | x1 |
| Speaker Type | 3-way floorstander |
| Crossover | Exakt digital |
| On-board Amps | 3x 100 W |
| Bass System | Isobarik |
| Tweeter | 19mm Silk dome with anti-resonant chamber |
| Midrange | 133mm Doped 2-layer slice |
| Bass | 165mm 2x Isobarik |
| Selekt DSM: Classic Hub | Classic Black or Classic Silver |
| Selekt DSM: Edition Hub | Edition Black or Edition Silver |
| Standard Fabrik | Aubergine, Black, Blueberry, Butterscotch, Paprika |
| Special Fabrik - Harris Tweed | Barley, Granite, Grouse, Peat, Spruce |
| Loudspeaker Stand & Top Plate | Black, White |
| Width | 232 mm |
| Height | 954 mm |
| Depth | 325 mm |
| Weight | 30 kg |
| Cabinet Volume | 30 litres |
