Nordost · Cables

HEIMDALL 2 IKABLE

Specialty cable with 4 x 24 AWG silver-plated OFC conductors.

fig. 01 · cables

HEIMDALL 2 IKABLE

Nordost HEIMDALL 2 IKABLE
fig. 01 · HEIMDALL 2 IKABLEphotograph · Nordost

From Nordost

Heimdall 2 iKable is a Norse 2 specialty cable for portable or line-level digital-library playback connections. The saved specs list 4 x 24 AWG silver-plated solid-core OFC conductors, FEP insulation, Dual Mono-Filament construction, 97% shield coverage, 25.0pF/ft capacitance, and 85% velocity of propagation. Connector options include dual MoonGlo RCA, 3.5mm stereo mini to 3.5mm stereo mini, and dual XLR.

Specifications

InsulationFluorinated Ethylene Propylene (FEP)
ConstructionMechanically tuned lay, length and Dual Mono-Filament design
Conductors4 x 24 AWG
MaterialSilver-plated 99.99999% solid-core OFC
Capacitance25.0pF/ft
Inductance0.06μH/ft
Overall Shield Coverage97%
Velocity of Propagation85%
TerminationGold-plated connectors available in (2x) Nordost MoonGlo® RCA, 3.5mm stereo mini to 3.5mm stereo mini, (2x) XLR
Conductor materialsilver-plated solid-core OFC
All 10 specificationsFewer specifications
