RED DAWN 3 POWER CORD
Power cord with 3 x 12 AWG OFC conductors.
fig. 01 · power cables
RED DAWN 3 POWER CORD
From Nordost
Red Dawn 3 Power Cord is a Nordost AC power cable with FEP extrusion and Micro Mono-Filament construction. It uses 3 x 12 AWG, 168-strand 99.9999% OFC conductors. Listed termination options include US, EU, UK, or AUS mains plugs to IEC-C15 or IEC-C19 connectors.
Specifications
| Insulation | Fluorinated Ethylene Propylene (FEP) |
|---|---|
| Construction | Mechanically tuned lay, Micro Mono-Filament design |
| Conductors | 3 x 12 AWG |
| Material | 168 strand 99.9999% OFC |
| Capacitance | 8.5pF/ft |
| Inductance | 0.121µH/ft |
| DC Resistance | 1.64 Ohms per 1000ft |
| Termination | US (Nema), EU (Schuko), UK or AUS to IEC-C15 or IEC-C19 connectors. |
| Conductor count | 3 |
| Conductor gauge | 12 AWG |
| Dielectric / insulation | FEP extrusion |
| Geometry / construction | Micro Mono-Filament |
