Octave · Integrated Amplifiers
V 110 SE
The V 110 SE is a tube amplifier with three switchable damping factor settings (swap an input tube, no rewiring), delivering 110W RMS at 4 ohms.
fig. 01 · integrated amplifiers
V 110 SE
current
8 photographs · 5 shown
From Octave
Octave ships the V 110 SE with two extra input tubes beyond the factory-installed MED setting, each carrying different gain characteristics that shift the amplifier's damping factor when swapped in. HIGH suits electrostatic or dipole speakers with a dip in mid-high impedance, LOW works better with high-efficiency horn designs, and MED, the default, handles speakers with large midrange domes and a rising impedance curve.
The amplifier runs four KT88-S4A-Carbon tubes standard, with KT120 TS or KT150 TS available as options. Output power reaches 110W RMS at 4 ohms in High mode and 70W RMS in Low mode, across a 20Hz to 70kHz frequency response measured at 90W.
Six line-level RCA inputs (one bypass, one phono-capable with the optional MC or MM board) join a single XLR input, feeding a regulated preamp output, record output, and speaker terminals. Eco Mode, HT Bypass, and a connection for the Black Box or Super Black Box power supply extension carry over from the rest of the Octave all-in-one amplifier range.
Specifications
| Basic Model | V 110 SE Line |
|---|---|
| Options | Phono MC or MM |
| Design | Silver or Black |
| Tube Configuration | 4 x KT 88-S4A-Carbon, optional 4 x KT 150 TS or KT 120 TS |
| Inputs | 6 x line level RCA (one is a bypass input and one is a phono input with option phono), 1 x XLR |
| Outputs | 1 x Pre-Out regulated / 1 x Record output RCA / 1 x Loudspeaker output |
| Dimensions | 451 x 175 x 415 mm (W x H x D) |
| Weight | 22.3 kg |
| Eco Mode | Power saving mode |
| Bias Control | Bias current control |
| Adjustable Pre-Out | Preamp output RCA |
| HT Bypass | Bypass-function for multichannel/home cinema |
| Protection system | Soft Start; Protection circuit for amplifier and output tubes |
| Power selection | For different output tubes |
| Adjustable damping factor | To adjust to the loudspeaker |
| Full metal remote control | Volume control |
| Output power | High: 110 W (RMS) /4 ohms; Low: 70 W (RMS) /4 ohms |
| Frequency response | 20 Hz - 70 kHz @90 W - 1 / - 3 dB |
| Total harmonic distortion | 0.1% at 10 W into 4 ohms |
| Signal-to-noise ratio | - 100 dB / 90 W |
