Prima Luna · Integrated Amplifiers
PrimaLuna EVO 400 Tube Integrated Amplifier
PrimaLuna's EVO 400 tube amp with EL34, KT88, KT120, and KT150 operating ranges.
fig. 01 · integrated amplifiers
PrimaLuna EVO 400 Tube Integrated Amplifier
8 photographs · 5 shown
From Prima Luna
The EVO 400 Tube amp is the widest-output tube amp in the EVO line. Its specs cover EL34, KT88, KT120, and KT150 operation, with ultra-linear and triode modes, 5 stereo RCA inputs, a home-theater input, speaker taps, tape, subwoofer, and headphone outputs.
Specifications
| Model | Model EVO 400-1 for EL34 / KT88 / KT120 / KT150 |
|---|---|
| Power Ultra-Linear | 70 / 72 / 85 / 88 Watts per channel |
| Power Triode | 38 / 40 / 45 / 50 Watts per channel |
| Frequency Response | 9 Hz – 50 kHz +/- 1 dB8 Hz – 68 kHz +/- 3 dB |
| THD with AABB | < 0.1% @ 1W; < 2% @ Rated Power |
| S/N Ratio | 90 dB – 98 dB A Weighted |
| Input Impedance | 100 kOhm |
| Input Sensitivity | 320 / 320 / 360 / 370 mV for rated power at max volume |
| Maximum Gain Ultra-Linear | 37 dB / 37.5 dB / 37.5 dB / 36.9 dB |
| Maximum Gain Triode | 36.5 dB / 36 dB / 36 dB / 36 dB |
| Power Consumption | 470 Watts / 480 Watts / 540 Watts / 550 Watts |
| Weight | Net weight: 68.2 lbs / 31 kg Shipping Weight: 79.2 lbs / 36 kg |
| Dimensions | 15.9" x 15.2" x 8.1" / 405 x 385 x 205 mm (L x W x H) |
| Shipping dimensions | 22.7" x 18.4" x 12.4" / 577 x 468 x 315 mm (L x W x H) |
| Inputs | 5 pairs Stereo RCA, 1 pair Home Theater Input |
| Outputs | 4 & 8 Ohm Speaker Taps, Tape, Stereo/Mono Sub, Headphone |
| Tube Complement | 8 x EL34, 6 x 12AU7 |
| Damping Coefficient | 7 KD (1 kHz) |
| Remote Control | Full |
| Product type | tube integrated amplifier |
| Series | EVO 400 |
