AVR21
The Arcam AVR21 is an HDA-series HDMI 2.1 Class AB AV receiver with 16 decoding channels.
fig. 01 · home theater electronics
AVR21
current
From Arcam
The Arcam AVR21 is an HDA-series AV receiver with HDMI 2.1 and HDCP 2.3, 7 HDMI inputs, and 3 outputs including Zone 2. It has 7 Class AB amplifier channels and decodes 16 audio channels through dual ESS 9026PRO DACs. It supports Dirac Live room correction, is Dirac Live Bass Control ready, and is Roon Ready.
Specifications
| Product type | HDMI 2.1 high-power Class AB AV receiver |
|---|---|
| HDMI inputs/outputs | 7 inputs / 3 outputs including Zone 2, eARC compatible |
| HDMI version | HDMI 2.1 with HDCP 2.3 |
| Amplifier class | Class AB |
| Amplifier channels | 7 |
| Audio decoding channels | 16 |
| Power output | 2 channels driven, 20Hz - 20kHz, <0.02% THD: 110W/175W at 8 Ohms / 4 Ohms | 2 channels driven, 1kHz, 0.2% THD: 125W/190W at 8 Ohms / 4 Ohms | 7 channels driven, 1kHz, 0.2% THD: 90W/110W at 8 Ohms / 4 Ohms |
| DAC | dual ESS 9026PRO DACs with ESS reference voltage regulators |
| Room correction | Dirac Live room correction | Dirac Live Bass Control ready |
| Streaming support | Google Chromecast built-in | Apple AirPlay 2 | Bluetooth aptX HD | Spotify Connect | Tidal Connect | UPnP MusicLife app | Roon Ready | MQA |
| Input impedance | 47k Ohms |
| Signal/noise ratio | 100dB/110dB (A-wtd ref 100W, normal/stereo direct) |
| Frequency response | 20Hz - 20kHz +/- 0.2dB |
| Dimensions | 433 x 425 x 171mm |
| Weight (net) | 16.6kg |
| Weight (packed) | 19.9kg |
