Arcam · Home Theater Electronics
AVR5
The Arcam AVR5 is an HDA-series Class AB AV receiver with 7 amplifier channels.
fig. 01 · home theater electronics
AVR5
current
From Arcam
The Arcam AVR5 is an HDA-series AV receiver with HDMI 2.0b and HDCP 2.2, 7 HDMI inputs, and 2 outputs. It has 7 Class AB amplifier channels and decodes 12 audio channels through an ESS 9026PRO DAC. It's Dirac Live room correction ready, Roon Ready, and supports MQA.
Specifications
| Product type | Class AB AV receiver |
|---|---|
| HDMI inputs/outputs | 7 inputs / 2 outputs, eARC compatible |
| HDMI version | HDMI 2.0b with HDCP 2.2 |
| Amplifier class | Class AB |
| Amplifier channels | 7 |
| Audio decoding channels | 12 |
| Power output | 2 channels driven, 20Hz - 20kHz, <0.02% THD: 80W/100W at 8 Ohms / 4 Ohms | 2 channels driven, 1kHz, 0.2% THD: 85W/120W at 8 Ohms / 4 Ohms | 7 channels driven, 1kHz, 0.2% THD: 60W/85W at 8 Ohms / 4 Ohms |
| DAC | ESS 9026PRO DAC |
| Room correction | Dirac Live room correction ready |
| Streaming support | Google Cast/UPnP | Apple AirPlay 2 | Bluetooth aptX HD | Spotify Connect | UPnP MusicLife app | Roon Ready | MQA |
| Input impedance | 47k Ohms |
| Signal/noise ratio | 100dB/110dB (A-wtd ref 100W, normal/stereo direct) |
| Frequency response | 20Hz - 20kHz +/- 0.2dB |
| Dimensions | 433 x 425 x 171mm |
| Weight (net) | 16.5kg |
| Weight (packed) | 19.8kg |
