Arcam · Speakers · Bookshelf Speakers
R25 (Coming Soon)
The Arcam R25 is a Radia-series bookshelf loudspeaker pair with 43Hz-40kHz frequency response.
fig. 01 · speakers
R25 (Coming Soon)
7 photographs · 5 shown
From Arcam
The Arcam R25 is a Radia-series bookshelf loudspeaker pair in a black natural walnut veneer cabinet. It pairs a 165mm MCC low-frequency driver with a 25mm DCC dome tweeter, runs at 6-ohm nominal impedance, and has a 43Hz-40kHz frequency response. Recommended amplifier power is 15 to 200W.
Specifications
| Type | Bookshelf Loudspeakers |
|---|---|
| Cabinet Finish | Black Natural Walnut Veneer |
| Recommended Amplifier Power | 15-200W |
| Low Frequency Driver | 165mm (6.5 in) Micro Ceramic Composite (MCC) Cone with inverted surrounds in patented cast frames |
| High Frequency Driver | 25mm (1 in) Deep Ceramic Composite (DCC) Dome Tweeter in a patented waveguide with acoustic lens |
| Enclosure Tuning | Bass-Reflex via Rear-Mounted Port |
| Crossover Frequency | 1.7 kHz |
| Nominal Impedance | 6 Ohms |
| Frequency Response ± 6dB | 43Hz-40kHz |
| Sensitivity @ 1M, 2.83V | 85.5 dB |
| Dimensions W x D x H | W 246 x D 323 x H 359mm (9.7 x 12.7 x 14.1 in) |
| Product Weight (each) | 11.0kg (24.3 lbs) |
| Shipping Weight | 27.0kg (59.5lbs) |
| Shipping Units of Measure | Pair |
