Arcam · Integrated Amplifiers
SA35
The Arcam SA35 is a streaming amplifier delivering 120W per channel into 8 ohms.
fig. 01 · integrated amplifiers
SA35
current
7 photographs · 5 shown
From Arcam
The Arcam SA35 is a streaming amplifier that delivers 120W per channel into 8 ohms. It has MM and MC phono inputs, an HDMI eARC connection, coaxial and optical digital inputs, Bluetooth 5.4, and Wi-Fi.
Specifications
| Services | Works with (apps): | ARCAM Radia | Spotify (Connect) | Tidal (Connect) | Qobuz (Connect) | Roon Ready |
|---|---|
| Continuous power output (0.5% THD), per channel | 2 channels driven, 20Hz. 20kHz, 8O: 120W | 2 channels driven, 1kHz, 4O: 200W | Harmonic distortion, 80% power, 8O at 1kHz: 0.002% |
| Analogue Inputs | Number of inputs: 3 (RCA pairs) | Phono Inputs: MM and MC | Frequency response: 20Hz.20kHz ± 0.2dB | Signal/noise ratio (A-wtd, ref. 50W, 1V input): 106dB |
| Digital Inputs | Supported Streaming media: FLAC, WAV (LPCM), AAC, ALAC, AIFF, DSD (up to 256), MP3, MP4, OGG, WMA | Supported Streaming Bit depth: 16, 24, 32 | Supported Streaming sample rates (kHz): Up to 384 kHz | Gapless Playback: Yes | Digital Audio Inputs: 1x HDMI eARC, 2x Coaxial (RCA), 2x Optical (Toslink) | Supported Digital input Bit depth: 16, 24 | Supported Digital input sample rates (kHz): Up to 192 kHz | Frequency response (filter 1): 20Hz.20kHz ± 0.2dB | Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 110dB |
| Wireless Specifications | Bluetooth Profile 5.4; A2DP Sink/Source, AVRCP, BLE, Snapdragon Sound, AAC, LE Audio, Auracast | Bluetooth Transmitter Frequency and Power: 2,400 MHz to 2,483.5 MHz: <20dBm | Wi-Fi Network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz) | 2.4G Wi-Fi Transmitter Frequency Range and Power: | 2400-2483.5 MHz (USA 11 Channels, Europe and Others 13 Channels): <20dBm | 5G Wi-Fi Transmitter Frequency Range and Power: | 5150-5250 MHz <23dBm | 5250-5350 MHz <20dBm | 5470-5725 MHz <20dBm (Not used in China) | 5725-5850 MHz <14dBm for EU, <33dBm for other regions. |
| General | Mains voltage: 100V or 110–120V or 220–240V, 50–60Hz | Power consumption (maximum): 700W | Power consumption (standby): <0.5W | Dimensions W x D (including speaker terminals) x H (including feet): | 432 x 344 x 99mm | Weight (net): 12 kg | Weight (packed): 14 kg |
| Supplied accessories | Mains lead(s) | Remote control with 2 x AAA batteries | Measurement Microphone | 5m USB Cable | Quick Start Guide | Important Safety Instructions |
| Streaming / digital platform | all-new digital audio and streaming platform |
