Audiolab · Integrated Amplifiers
6000A
The 6000A is a 6000 Series stereo amp with analogue, digital, Bluetooth, phono, headphone, and speaker connections.
fig. 01 · integrated amplifiers
6000A
45912300945688
From Audiolab
The 6000A is Audiolab's compact system amp for mixed source setups. The saved specs document a 445mm-wide chassis, 7.8kg net weight, analogue and digital input support, headphone output, and speaker terminals.
Specifications
| Gain (max.) | +8dB (Line) +55dB (Phono MM) |
|---|---|
| Input Sensitivity | 720mV |
| Input Impedance | 10K (Line)47K//100pF (Phono MM) |
| Total Harmonic Distortion (THD) | < 0.01% (1kHz, 50mW) |
| Frequency Response | 20Hz-20kHz (+/-0.3dB) |
| Output Voltage | 2.3V max. (Volume = 0dB) |
| Output Impedance | 2.35Ω |
| Signal-to-Noise Ratio (S/N) | > 110dB (Line, A-weighted)>76dB (Phono MM, A-weighted) |
| D to A converter | ES9018K2M |
| Output level (0dBFS, 1KHz) | 2.05V |
| Max. Sampling Frequency | 192kHz |
| Signal-to-noise ratio (S/N) | > 112dB (A-weighted) |
| Digital Filters | Fast Roll-off , Slow Roll-off , Minimum Phase |
| Gain | +29dB |
| Rated Max. Power Output | 2 X 50W (8Ω, THD<1%)2 X 75W (4Ω, THD<1%) |
| Signal-to-Noise ratio (S/N) | > 110dB (A-weighted) |
| Max. Output Current | 9A |
| Load impedance | 20-600Ω |
| Standby Power Consumption | <0.5W |
| Power Requirements | 240V ~ 50 - 60Hz230V ~ 50 - 60Hz115V ~ 50 - 60Hz100V ~ 50 - 60Hz |
| Dimensions (mm) (W x H x D) | 445 x 80 x 330mm including feet, terminals and controls |
| Carton Size (mm) (W x H x D) | 512 x 467 x 146 |
| Weight | 7.8kg (Net) |
| Product type | integrated amplifier |
| Series | 6000 Series |
