6000A MKII
The 6000A MKII adds HDMI ARC and ES9038Q2M conversion to the 6000 Series stereo amp format.
fig. 01 · integrated amplifiers
6000A MKII
49889606009112
From Audiolab
The 6000A MKII updates Audiolab's 6000 Series amp around a 50W-per-channel output rating into 8 ohms. Its source specs list MM phono, coaxial, optical, HDMI ARC, Bluetooth, headphone, preamp, and speaker connections.
Specifications
| General Description | Integrated Amplifier |
|---|---|
| Design Philosophy and Core Technology | 2x50W (8 ohms) / 2x75 (4 ohms)Class AB DesignES9038Q2M 32-bit DACBluetooth 5.1 (aptX / aptX HD)Dedicated High Performance Low Noise MM Phono stageDedicated Current-Feedback Headphone AmpIntegrated / Pre-Power / Pre Modes only Modes |
| Inputs | 3 x Analogue, 1 x Phono (MM), 1 x Power Amplifier,2 x SPDIF (Coax), 2 x SPDIF (Optical), 1 x HDMI ARC,1 x Bluetooth (aptX / aptX HD), 1 x 12V Trigger |
| Outputs | 1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger |
| Sampling Frequency | Optical / Coaxial: 44.1kHz-192kHz |
| Gain | +29dB |
| Input Sensitivity | 720mV (Line, Volume = 0dB); 3.1mV (Phone MM, Volume = 0dB) |
| Input Impedance | 10K (Line); 47k/100pF (Phono MM) |
| Total Harmonic Distortion (THD) | <0.001% (1KHz @ 0dBFS) |
| Frequency Response | 20Hz-20kHz (+/-0.3dB) |
| Output Voltage | 2.3V max. (Volume = 0dB) |
| Output Impedance | 120 ohms |
| Signal-to-Noise Ratio | >110dB (Line, A-weighted); > 79dB (Phono MM, A-weighted) |
| D to A Converter | ES9038Q2M |
| Output Level (OdBFS, 1kHz) | 2.05Vrms |
| Max.Sampling Frequency | Optical, Coaxial: 192kHz; |
| Signal-to-Noise Ratio (S/N) | >109dB (A-weighted) |
| Rated Power Output | 2 x 50W (8 ohms, THD<1%); 2 x 75W (4 ohms, THD<1%) |
| Total Harmonic Distortion (THD) Input Sensitivity | <0.003% (1kHz @ 50W / 8 ohms)720mV |
| Max. Output Current | 11A |
| Product type | integrated amplifier |
| Series | 6000 Series |
