Audiolab · Music Servers & Streamers
6000N Play
The 6000N Play is a 6000 Series network streamer with DTS Play-Fi, ES9018K2M conversion, coaxial output, and optical output.
fig. 01 · music servers & streamers
6000N Play
45335313809688
From Audiolab
The 6000N Play gives the 6000 Series a wireless network source. Its saved specs list DTS Play-Fi streaming, an ES9018K2M DAC, coaxial and optical digital outputs, and high-resolution playback through the streaming platform.
Specifications
| Digital Output Level | 500 +/- 50mVpp |
|---|---|
| Output Impedance | 75Ω |
| Maximum Resolution | 192kHz/24bit |
| Digital Output | 1 x coaxial , 1 x optical |
| Variable Output Voltage | 0 - 2.1V |
| DAC | ES9018K2M |
| Frequency Response | +/-0.5dB(20Hz-20kHz,ref.1kHz) |
| Total Harmonic Distortion (THD) | <0.003% (1kHz @0dBFS , BW=20-20kHz) |
| Signal-to-noise Ratio (S/N) | >115dB(A-weighted) |
| Analogue Output Impedance | 100Ω |
| Standby Power Consumption | <0.5W |
| Requirements (depending on region) | 220V-240V~50/60Hz100V-120V~50/60Hz |
| Dimensions (LxHxW) | 445 x 80 x 330mm. including feet, terminals and controls |
| Net Weight | 4.9kg |
| Product type | network streamer |
| Series | 6000 Series |
| Streaming platform | DTS Play-Fi |
