9000N
The 9000N is a 9000 Series network streamer with ES9038Pro conversion, Ethernet, USB-B, RCA, XLR, optical, and coaxial outputs.
fig. 01 · music servers & streamers
9000N
45912453873944
From Audiolab
The 9000N is Audiolab's 9000 Series network source for wired and app-based playback. Its source specs list FLAC, ALAC, WAV, AIFF, MP3, DSD, DIFF, and DoP support, plus PCM up to 768kHz and native DSD512.
Specifications
| Model | 9000N |
|---|---|
| General Description | Network Player |
| The audiolab 9000N App Features | Native support for TIDAL, Qobuz and TuneIn RadioTidal icons to easily identify high-res musicQobuz high-res icons to identify high-res musicVolume controlHigh-resolution album artwork displayArtwork cachingIntelligent search functionalityMultiple Playlist complications & functionalityMultiple tag handlingComposer tag supportAlbum-grouping in playlistAutomatic internet links to artists / album / songsSaving and restoring of playlists (including Tidal and Qobuz) |
| Inputs | 1 x Network Streaming1 x PC USB (USB Type-B)1 x Ethernet 10/100 / 1000 Base-T Ethernet1 x 12V Trigger |
| Outputs | 1 x RCA (pair)1 x XLR (pair)1 x Optical1 x Coaxial1 x 12V Trigger (Link) |
| Supported File Formats | DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFFCompressed (lossy) Audio: MP3 |
| Sampling Frequency | PCM: 44.1kHz-768kHz (705.6kHz / 768kHz Fixed-point supported via Audiolab 9000N App streaming)DSD: DSD64, DSD128, DSD256, DSD512 (Native) |
| Digital Output Voltage | 500mV +/- 50mVpp |
| Output Impedance | 120Ω |
| Frequency Response | +/-0.5dB (20Hz - 20kHz, ref.1kHz) |
| Max. Sampling Frequency | 768kHz / 32bit |
| Digital Outputs | 1 x Coaxial , 1 x Optical |
| Variable Output Voltage | 0 - 2.05V |
| DAC | ES9038Pro |
| Total Harmonic Distortion | <0.001% (1kHz @ 2.05Vrms) |
| Signal-to-noise ratio (A-weighted) | >116dB(RCA), >120dB(XLR) |
| Standby Power Consumption | <0.5W |
| Net Weight | 6.2kg |
| Gross Weight | 8kg |
| Dimensions (mm)(W x H x D) | 444 x 89 x 333 |
| Carton Size (mm)(W x H x D) | 514 x 470 x 161 |
| Finish | Black / Silver |
| Power Requirements(depending on region) | 220-240V ~ 50/ 60Hz100-120V ~ 50/ 60Hz |
| Standard Accessories | Power Cord, Remote Control, User Manual |
| Product type | network streamer |
| Series | 9000 Series |
