Focal · Speakers · In-wall & In-ceiling Speakers
100 IW6
The 100 IW6 is a compact 2-way in-wall loudspeaker with a 6.5-inch Polyglass driver for flush home installation.
fig. 01 · speakers
100 IW6
8 photographs · 5 shown
From Focal
A 6.5-inch Polyglass midbass driver delivers full sound from a shallow, compact in-wall enclosure that mounts with just 88mm of depth. It suits hallways, living rooms, bedrooms, and kitchens for stereo listening, or channels for home theater, and takes a paintable grille for a clean, flush finish.
Specifications
| Type | In-wall 2-way |
|---|---|
| Drivers | 61/2" (16.5cm) Polyglass Midbass |
| Sensitivity (2.83V/1m) | 89dB |
| Frequency response (+/-3dB) | 60Hz-23kHz |
| Low frequency point (-6dB) | 48Hz |
| Nominal impedance | 8Ω |
| Minimal impedance | 7,2Ω |
| Recommended amplifier power | 25-120W |
| External dimensions (Ø/Depth) | 113/4"x711/16"x35/8" (298x195x92mm) |
| Cut-Out diameter | 103/4"x611/16" (273x170mm) |
| Depth from wall | 37/16" (88mm) |
| Net weight (with front grille) | 4,1lbs (1.85kg) |
| Packing dimensions (WxDxH) | 131/2"x97/16"x415/16" (343x240x126mm) |
| Total weight (with packaging) | 4.98lbs (2.25kg) |
