Cinema SUB
A bass-reflex subwoofer with two 13-inch W-cone woofers in one cabinet, built for large private cinema rooms up to 200 square meters.
fig. 01 · subwoofers
Cinema SUB
6 photographs · 5 shown
From Focal
Two 13-inch W-cone woofers share one bass-reflex cabinet tuned to a 19Hz port, mountable in-wall, on-wall, or freestanding. It needs external amplification, rated for 300W RMS at 4 ohms, and pairs with the Cinema LCR for a matched system. It fills private cinema rooms as large as 200 square meters (2,153 sq ft).
Specifications
| Type | Subwoofer bass-reflex | In-wall / On-wall / Freestanding |
|---|---|
| Tuned port | 19Hz |
| Speaker drivers | 2x13" 'W' cone woofers |
| Sensivity (2.83V/3feet - 1m) | 95dB (66Hz) |
| Bandwidth (-3dB) 2Pi | 42Hz - 2500Hz |
| Low-frequency cut-off (-10dB) | 19Hz - 2500Hz |
| Recommanded EQ | 19Hz - 2500Hz ±1dB | +12dB @20Hz Q=1.8 and shelving -5dB @50Hz (1st order) | and 24 dB/oct @18Hz butterworth |
| Nominal impedance | 5Ω |
| Minimal impedance | 4.1Ω to 19Hz |
| Crossover | No |
| Rated power | 300W RMS (4Ω) |
| Recommended amp power | Max 400W (8Ω) / Max 800W (4Ω) |
| Dimensions (HxWxD) | 45 7/8 "x21 5/8 "x12 13/16 " (116.5x54.9x32.6cm) |
| Net weight | 160.94lbs (73kg) |
