Littora 1000 ICW 10
The Littora 1000 ICW10 flush-mounts in walls or ceilings, pairing a 10-inch driver with a beryllium tweeter and IP65-rated waterproofing.
fig. 01 · speakers
Littora 1000 ICW 10
6 photographs · 5 shown
From Focal
This 10-inch outdoor speaker has a shallow mounting depth for a flush install in walls or ceilings. A beryllium tweeter handles the highs, backed by IP65-rated protection against water and dust, rated from -25°C to 90°C. The ready-to-paint grille blends into any exterior finish. Made in France.
Specifications
| Type of speaker | LITTORA 1000 ICW10 |
|---|---|
| Diameter | 10" |
| Recommended amp power | 50 – 200W |
| Nominal impedance | 8Ω |
| Minimal impedance | 4.3Ω at 150Hz |
| Sensitivity (2.83 V/3ft - 1m) | 92dB |
| Frequency response | 38Hz – 40kHz |
| High-pass, slope | 65Hz, 24dB/Oct - 65Hz, 24dB/Oct |
| Closed box volume 1, F -3dB | 15L, 63Hz |
| Closed box volume 2, F -3dB | 10L, 74Hz |
| Free air, F -3dB | 60Hz |
| Tweeter | Beryllium |
| IP certification | IP65 (ASTMB117) |
| Tweeter setting | -3/0/+3dB |
| Crossover setting | Indoor/Outoor switch |
| Grille | Ready-to-paint aluminium |
| UV resistance | Yes (ASTMG53) |
| Operating temperatures | -25°C to 90°C |
| Number of mounting points | 6 |
| Connector | DT06-2S sealed |
| Mounting depth | 43/4" (122mm) |
| Certifications | ROHS, ROHS 2, CHINA ROHS, REACH |
| Weight | 4kg |
