On Wall 302
On Wall 302 is a slim, surface-mounted on-wall speaker for screens above 60 inches, built with high power handling.
fig. 01 · speakers
On Wall 302
8 photographs · 5 shown
From Focal
This 2.5-way on-wall speaker mounts to the wall or sits on optional stands, sized for screens above 60 inches. Four 4 inch Flax midbass drivers and a tweeter cover 50Hz to 28kHz, with high power handling for home cinema use. It comes in white high gloss or black satin.
Specifications
| Type | 2.5-way loudspeaker |
|---|---|
| Drivers | 4 x 4" (100mm) Flax MidBass | 1 x 1" (25mm) Tweeter TNF |
| Sensitivity (2.83V/1m) | 91dB |
| Frequency response (±3dB) | 50Hz - 28kHz |
| Low frequency point (-6dB) | 40Hz |
| Nominal impedance | 8 Ω |
| Minimum impedance | 5 Ω |
| Recommanded amplifier power | 40 - 180W |
| Crossover frequency | 1,100Hz - 2,500Hz |
| Dimensions (HxWxD) | 49 3/16 x6 1/8 x3 9/16 " (125x15.5x9cm) |
| Net weight (unit with grille) | 20.72lbs (9.4kg) |
| Packaging dimensions (HxWxD) | 54 5/16 x11 13/16 x8 1/4 " (138x30x21cm) |
| Net weight (with packaging) | 26.45lbs (12kg) |
