Focal · Subwoofers
Sub 600P
Sub 600P is a self-powered closed-box subwoofer with a built-in 600W Class-D amplifier for stereo or home theater.
fig. 01 · subwoofers
Sub 600P
8 photographs · 5 shown
From Focal
Sub 600P pairs a 12-inch (30cm) Polyflex woofer with a built-in 600W Class-D amplifier (300W RMS) in a closed cabinet for deep, controlled bass down to 26Hz (-6dB). Right, left, and LFE RCA inputs connect it to a stereo or home theater system, with a variable 40-200Hz crossover and 0°/180° phase switching.
Specifications
| Type | Active closed subwoofer |
|---|---|
| Speaker driver | 12" (30cm) Polyflex woofer |
| Frequency response at -6dB | 26Hz |
| Frequency response (+/-3dB) | 28Hz-270Hz |
| RCA input | Right, left LFE |
| Crossover frequency | Variable 40Hz-200Hz (LFE) |
| Phase adjustment | Phase inverter 0°/180° |
| Power modes | AutoStandby enable/disable |
| Amplifier power | 600W Dynamic (300W RMS) |
| Dimensions (HxWxD) | 15 3/4 "x15 3/4 "x16 3/4 " | (400x400x425mm) |
| Weight | 46.3lbs (21kg) |
