Mission · Speakers · Center Channel Speakers
LX-C2 MKII
The LX-C2 MKII is a center-channel loudspeaker in Mission's LX MKII Series, with two 5-inch composite-fibre bass drivers, a 25 mm tweeter, and a closed-box cabinet.
fig. 01 · speakers
LX-C2 MKII
538897
out of stock
6 photographs · 5 shown
From Mission
The LX-C2 MKII is a 2-way center-channel loudspeaker in Mission's LX MKII Series. It has two 5-inch bass drivers, a 1-inch soft-dome treble unit, Mission's Inverted Driver Geometry layout, and DiaDrive bass-unit engineering carried over from the ZX line. The closed-box cabinet delivers 65 Hz to 20 kHz frequency response and 89 dB sensitivity, recommended for 20 to 120 W amplifiers, and it weighs 8.8 kg.
Specifications
| General description | 2-way bookshelf speaker Bass extension(-6dB) 60Hz |
|---|---|
| Enclosure type | closed-box system Crossover frequency 3.2kHz |
| Transducer complement | 2-way Cabinet Volume (in litres) 12.5L |
| Bass driver | 5"(130mm) composite fibre x2 Height (on plinth) 180mm |
| Width | 500mm |
| Treble driver | 25mm microfibre dome Depth (with terminals) (230+8)mm |
| AV shield | No Carton size 595 x 330 x 275mm |
| Sensitivity (2.83V @ 1m) | 89dB Net weight 8.8kg/pcs |
| Recommended amplifier power | 20-120W Gross weight 10.4kg/ctn |
| Peak SPL | 105dB Finish Walnut Pearl / Lux White / Lux Black |
| Nominal impedance | 8 Ohms Compatible |
| Minimum impedance | 4.3 Ohms |
| Frequency response (+/-3dB) | 65Hz ~ 20kHz |
| Product type | center-channel loudspeaker |
| Series | LX MKII |
| Speaker type | 2-way center-channel speaker |
| Bass drivers | two 5 inch drivers |
