Pathos · DACs
Converto MK2
The Pathos Converto MK2 is a DAC and headphone amp with a balanced Class A analog stage, USB inputs, and a variable output level.
fig. 01 · dacs
Converto MK2
From Pathos
The Converto MK2 handles digital and analog inputs in a compact DAC and headphone amp. It supports PCM up to 32-bit/384kHz and DSD128 over USB, runs a balanced Class A zero-feedback analog stage, has balanced XLR and RCA outputs, and puts out 1W at 16 ohms from the headphone jack.
Specifications
| Digital input sample rate | S/PDIF 32bit up to 384 KHzUSB from Pc - PCM 32bit up to 384kHz, DSD64, DSD128 |
|---|---|
| Analog stage | Fully balanced, class A, zero feedback |
| Dynamic range | 120dB |
| S/N ratio | -110dB |
| THD | < 0,02% |
| Analogue output | 1x Balanced XLR, one Unbalanced RCA line |
| Output impedance | <0,2 Ohm |
| Max fixed output level | 3,2 V RMS |
| Variable output level | 0 - 6,3 V RMS |
| Inputs | 2x USB type "B" connector for computer 1x digital S/PDIF RCA1x digital S/PDIF optic toslink1x analog stereo line RCA |
| Output power | 1W @ 16 Ohm |
| Output level | 7 VRMS |
| Frequency response | 10Hz - 100 KHz |
| Mains voltage | 90-250V 50/60Hz |
| Power consumption | 10W |
| Dimensions | 200 x 226 x 70 mm |
| Weight | 2,5 Kg |
| Product type | DAC and headphone amplifier |
