Pathos · Preamplifiers
Synapse
Tube preamp with balanced XLR input and output paths, 6H30 tubes, and stepped volume control.
fig. 01 · preamplifiers
Synapse
From Pathos
Synapse is Pathos' balanced preamp partner for the Adrenalin power amp. The saved specs list 3 balanced XLR inputs, 2 main balanced XLR outputs, 4 6H30 tubes, 1Hz to 100kHz response, and 0.5dB volume steps.
Specifications
| Inputs | 3 balanced XLR |
|---|---|
| Outputs | 2 main balanced XLR |
| Frequency response | 1Hz - 100KHz |
| THD | 0,04% @ 4 Vrms |
| Volume control | 0,5dB - 168 steps |
| Tubes | 4x 6H30 |
| Dimensions | 530mm (D) x 430mm (W) x 260mm (H) |
| Weight | 23Kg |
| Product type | preamplifier |
