Quad · Speakers · Bookshelf Speakers
S-2
A larger S Series bookshelf speaker with ribbon treble.
fig. 01 · speakers
S-2
From Quad
S-2 is the larger bookshelf model in the S Series, with ribbon treble and a midrange driver layout. It fits rooms where a standmount speaker can use more cabinet volume than the S-1.
Specifications
| Model | S-2 |
|---|---|
| General description | bookshelf |
| Enclosure type | vented box |
| Transducer complement | 2-way |
| Midrange driver | 125mm Woven Kevlar® |
| Treble driver | 45 x 12mm true ribbon |
| Sensitivity (1W @ 1m) | 87dB |
| Recommended amplifier power | 25-150W |
| Nominal impedance | 8Ω |
| Minimum impedance | 4.5Ω |
| Frequency response (+/-3dB) | 48Hz - 22kHz |
| Bass Extension (-6dB) | 37Hz |
| Crossover frequency | 3kHz |
| Cabinet Volume (in litres) | 10.3L |
| Dimensions | 330 x 180 x (260 + 30)mm |
| Net weight | 6.1kg each |
| Product type | bookshelf loudspeaker |
| Series | S Series |
