Rotel · Power Amplifiers
C8+
The C8+ is an 8-channel custom installation amplifier delivering 150W per channel, bridgeable to 300W.
fig. 01 · power amplifiers
C8+
From Rotel
The C8+ drives 8 channels at 150W each in Class AB. Channels bridge to 300W into 4 ohms. It's the higher-powered version of the C8.
Built for custom installations with demanding speaker loads or larger zones.
Specifications
| Dimensions (W × H × D) | 430 × 97 × 414mm17" × 3.9" × 16.3" |
|---|---|
| Front Panel Height | 2U / 88.1mm (3.5") |
| Power Requirements | 120V, 60Hz |
| Power Consumption | 980W |
| Standby Power Consumption | Normal: <0.5W |
| Net Weight | 18.35kg (40.79lbs.) |
| BTU Rating (4Ω, 1/8th power) | 2744 BTU/h |
| Maximum Power Output | 150W/Ch (8 channels driven, 4Ω) |
| Continuous Power Output | 100W/Ch (8 channels driven, 8Ω) |
| Total Harmonic Distortion (THD) | <0.1% |
| Frequency Response | Line Level Inputs: 10Hz - 100kHz, +0dB, 0 ± 0.5dB |
| S/N Ratio (IHF "A" Weighted) | Line Level Inputs: 100dB |
