Rotel · Integrated Amplifiers
DX-5
The DX-5 is a personal audio stereo amplifier with an ESS SABRE DAC, Bluetooth, and Roon Tested certification.
fig. 01 · integrated amplifiers
DX-5
From Rotel
The DX-5 is a desktop-scale stereo amplifier designed for personal listening. An ESS SABRE DAC handles digital sources through coaxial, optical, and PC-USB inputs. Bluetooth connectivity is built in.
It carries Roon Tested certification. The compact industrial design is intended for desk or small-room use.
Specifications
| Dimensions (W × H × D) | 215 x 76 x 251mm8 1/2 x 3 x 10" |
|---|---|
| Front Panel Height | 70 mm (2 3/4") |
| Power Requirements | 120 V, 60 Hz |
| Power Consumption | 80 W |
| Standby Power Consumption | <0.5 W |
| Net Weight | 4.1 kg (9.1 lbs.) |
| BTU | 241 BTU/h |
| Power Output (FTC) | 25 W / ch |
| Total Harmonic Distortion | < 0.03% |
| Frequency Response | 10 Hz – 100k Hz (0 ± 0.19 dB) |
| Damping Factor (20 Hz – 20k Hz, 8 Ω) | 140 |
| Input Sensitivity / Impedance | 680 mV / 100k Ω |
| Input Overload | 4.2V |
| S/N Ratio (IHF "A" Weighted) | >100 dB |
