Rotel · Power Amplifiers
RB-1552 MkII
The RB-1552 MkII is a 2x130W stereo power amplifier sharing the RB-1582 MkII's platform.
fig. 01 · power amplifiers
RB-1552 MkII
From Rotel
The RB-1552 MkII is built on the same platform as the RB-1582 MkII with a 130W-per-channel output. The Balanced Design Concept and circuit topology carry over.
It's the entry point in Rotel's stereo power amplifier range.
Specifications
| Dimensions (W × H × D) | 431 × 144 × 339 mm17" × 5.7" × 13.4" |
|---|---|
| Front Panel Height | 3U / 132.6 mm (5.25") |
| Power Requirements | 120 V, 60 Hz |
| Power Consumption | 400 W |
| Standby Power Consumption | 0.5 W |
| Net Weight | 12.4 kg (27 lbs.) |
| BTU Rating (4 Ω, 1/8th power) | 905 BTU/h |
| Power Output | 130 W/Ch (8 Ω) |
| Total Harmonic Distortion (THD) | (20 Hz – 20k Hz) < 0.03% |
| Frequency Response | 10 Hz - 100k Hz ± 0.5 dB |
| S/N Ratio (IHF "A" Weighted) | 120 dB |
| Gain | RCA: 26.5 dB |
