Rotel · Preamplifiers
RC-1590MKII
The RC-1590MKII is Rotel's reference preamplifier with balanced XLR, analog, digital, Bluetooth, and turntable inputs.
fig. 01 · preamplifiers
RC-1590MKII
From Rotel
The RC-1590MKII is built as a reference-grade preamplifier. It accepts balanced XLR, unbalanced RCA, digital (optical, coaxial), PC-USB, Bluetooth, and phono (moving magnet) sources.
The DAC section runs at 32-bit/384kHz. Balanced XLR and unbalanced RCA outputs feed into a power amplifier.
It's the top of Rotel's preamplifier range.
Specifications
| Dimensions (W × H × D) | 431 × 144 × 348mm17" × 5.7" × 13.9" |
|---|---|
| Front Panel Height | 3U / 132.6mm (5.25") |
| Power Requirements | 120V, 60Hz |
| Power Consumption | 45W |
| Standby Power Consumption | <0.5W |
| Net Weight | 10.1kg (22.27bs.) |
| BTU Rating | 78 BTU/h |
| Total Harmonic Distortion (THD) | (20Hz–20kHz) <0.002% |
| Frequency Response | Line Level Inputs: 10Hz - 100kHz (+0dB, +0.1dB) |
| S/N Ratio (IHF "A" Weighted) | Line Level Inputs (RCA): 117dB |
