Rotel · Power Amplifiers
RMB-1506
The RMB-1506 is a 6x50W multi-channel amplifier for smaller multi-zone installations.
fig. 01 · power amplifiers
RMB-1506
From Rotel
The RMB-1506 delivers 6x50W per channel. It's a compact multi-channel amplifier for systems with a limited number of zones to fill.
The 6-channel layout fits distributed audio setups where each zone needs its own discrete amplifier channel.
Specifications
| Dimensions (W × H × D) | 431 × 144 × 424mm17" × 5.7" × 16.7" |
|---|---|
| Front Panel Height | 3U / 132.6mm (5.25") |
| Power Requirements | 120V, 60Hz |
| Power Consumption | 450W |
| Standby Power Consumption | 2.6W |
| Net Weight | 15.3kg (34lbs.) |
| BTU Rating (4Ω, 1/8th power) | 1680 BTU/h |
| Continuous Power Output | 50W/Ch (All channels driven, 8Ω) |
| Total Harmonic Distortion (THD) | (20Hz–20kHz) <0.03% |
| Frequency Response | 10Hz - 100kHz ±1dB |
| S/N Ratio (IHF "A" Weighted) | 115dB |
| Gain | 26dB |
