Rotel · Power Amplifiers
RMB-1585
The RMB-1585 is a 5x200W multi-channel power amplifier for large home theater speaker systems.
fig. 01 · power amplifiers
RMB-1585
From Rotel
The RMB-1585 delivers 5x200W per channel. It's the most powerful multi-channel amplifier in Rotel's range.
Designed for large home theater systems where each channel needs substantial headroom.
Specifications
| Dimensions (W × H × D) | 431 × 237 × 454mm17" × 9.4" × 17.9" |
|---|---|
| Front Panel Height | 5U / 221mm (8.75") |
| Power Requirements | 120V, 60Hz |
| Power Consumption | 1100W |
| Standby Power Consumption | 0.5W |
| Net Weight | 36kg (79lbs.) |
| BTU Rating (4Ω, 1/8th power) | 2372 BTU/h |
| Power Output | 200W/Ch (5 channels driven, 8Ω) |
| Total Harmonic Distortion (THD) | (20Hz–20kHz) <0.03% |
| Frequency Response | 10Hz - 100kHz +0.5, -3dB |
| S/N Ratio (IHF "A" Weighted) | 116dB |
| Gain | 26.5dB |
