Rotel · Power Amplifiers
RMB-1585MKII
The RMB-1585MKII is a 5-channel Class AB power amplifier for multi-channel home theater systems.
fig. 01 · power amplifiers
RMB-1585MKII
From Rotel
The RMB-1585MKII delivers 5 channels of Class AB amplification. It continues Rotel's approach to multi-channel amplifiers: high power, high current, and in-house manufacturing.
It's the 5-channel counterpart to the 7-channel RMB-1587MKII.
Specifications
| Dimensions (W × H × D) | 431 × 237 × 456 mm17" × 9.4" × 18" |
|---|---|
| Front Panel Height | 5U / 221 mm (8.75") |
| Power Requirements | 120 V, 60 Hz |
| Power Consumption | 1200 W |
| Net Weight | 37.4 kg (82 lbs.) |
| BTU Rating (4 Ω, 1/8th power) | 3317 BTU/h |
| FTC Power Output | 230 W/Ch (5 channels driven, 8Ω) |
| Power Output | 210 W/Ch (5 channels driven, 8Ω) |
| Total Harmonic Distortion (THD) | <0.03% |
| Frequency Response | 10H z - 100 kHz, +0.1 dB, -0.3 dB |
| Signal to Noise Ratio (A Weighting) | 120 dB |
| Gain | 26.9 dB |
