A 3000 HV Power amplifier
HV-series stereo amp with mono setup and 500 W into 4 ohms.
fig. 01 · power amplifiers
A 3000 HV Power amplifier
From T+A
A 3000 HV is a stereo HV-series power amplifier that can also be configured for mono use. In stereo specs it is rated at 300 watts into 8 ohms and 500 watts into 4 ohms, with 120,000 μF reservoir capacity, 1 Hz to 150 kHz power bandwidth, trigger input, and a 17 x 46 x 46 cm chassis.
Specifications
| Output stage: into 8 Ohmsinto 4 Ohms | 300 Watts500 Watts |
|---|---|
| Output stage: into 8 Ohmsinto 4 Ohms 2 | 380 Watts700 Watts |
| Output stage: into 8 Ohmsinto 4 Ohms 3 | 380 Watts650 Watts |
| Output stage: into 8 Ohmsinto 4 Ohms 4 | 430 Watts800 Watts |
| Output stage: Power bandwith | 1 Hz – 150 kHz |
| Output stage: Frequency response + 0 / – 3 dB | 0,5 Hz – 180 kHz |
| Output stage: Slew rate | 60 V/μs |
| Output stage: Damping factor | > 65 |
| Output stage: Signal / noise ratio | > 115 dB |
| Output stage: Total harmonic distortion | < 0,03 % |
| Output stage: Reservoir capacity | 120000 μF |
| Mains / Accessories / Dimensions: Mains | 110-120 V/60 Hz oder 220-240 V/50 Hz / 1500 W |
| Mains / Accessories / Dimensions: Standby | < 0,5 W |
| Mains / Accessories / Dimensions: Features | Trigger input +5 ... 20V for external switching-on |
| Mains / Accessories / Dimensions: Optional Accessories | PS 3000 HV Power Supply | Power Three HD (Carbon) | Power Bar | Audio Quad (Carbon) | Speaker Hex (Carbon) HV-Individual finish (Individual colours on request)| IP control |
| Mains / Accessories / Dimensions: Dimensions (H x W x D) | 17 x 46 x 46 cm |
| Mains / Accessories / Dimensions: Weight | 38 kg |
| Mains / Accessories / Dimensions: Finishes | Case: silver laquer 47 or titanium laquer 64,heat sink: black 42 |
| Operating mode | Class-A mode |
| Mono mode | configurable mono mode |
