G 2000 R Turntable
R-series belt-drive turntable with 33 1/3 and 45 rpm switching.
fig. 01 · turntables
G 2000 R Turntable
From T+A
G 2000 R is an R-series turntable with a belt-drive mechanism, structural sound absorber, and resonance isolation. It has electronically switched 33 1/3 and 45 rpm speeds, a pressure-cast aluminium platter, 20 Hz to 45 kHz pickup response, and R2-Link automatic power-on through a T+A amplifier.
Specifications
| Mechanics: Principle | Belt-drive High-End mechanism in special heavy chassiswith structural sound absorber and resonance isolation. |
|---|---|
| Mechanics: Platter motor | Crystal-controlled synchronous motor with precise DSP-controlled optimisation of the motor coil voltage curve |
| Mechanics: Rotational speeds | 33 1â„3 and 45 rpm electronically switched |
| Mechanics: Wow and flutter | +/− 0,02% |
| Mechanics: Rumble | 82 dB |
| Mechanics: Disc platter | Pressure-cast aluminium, weight 3,8 kg,with silicone rubber mat |
| Mechanics: Bearing technology | Hardened, polished steel shaft, close-tolerance plain brass bush |
| Pickup system: Output voltage | 0,75 mV |
| Pickup system: Channel separation 1kHz | 30 dB |
| Pickup system: Frequency response -3dB | 20 Hz – 45 kHz |
| Pickup system: Terminal impedance | 100 Ohm |
| Pickup system: Stylus compliance | 9 µm/mN |
| Pickup system: Style form | Micro Line |
| Pickup system: Tracking force | 20 mN (2 g) |
| Pickup system: Pickup weight | 8 g |
| Pickup system: Recommended phono amplifier | PHE-G R MC |
| Mains / Accessories / Dimensions: Control interface | R2-Link, automatic power-on via amplifier |
| Mains / Accessories / Dimensions: Mains | 100 – 240 V, 50 – 60 Hz, 40 W |
| Mains / Accessories / Dimensions: Stand | < 0,5 W |
| Mains / Accessories / Dimensions: Optional accessories | PHE-R MM or MC phono content_default (nur werkseitig montiert) | Power Three HD (Carbon) | Power Bar | Audio Triax (Carbon) | H 2000 turntable cover | PB 10 turntable brush | AG 10 pressure weight |
| Mains / Accessories / Dimensions: Dimensions (H x W x D) | Body 8,2 × 46 × 38 cmoverall 16 × 46 × 38 cm |
| Mains / Accessories / Dimensions: Weight | 14 kg |
| Mains / Accessories / Dimensions: Finishes | Silver anodised aluminium (43), black anodised aluminium (42), brushed |
