T+A · Power Conditioning
PS 3000 HV Power supply
Supplementary HV power supply with 240,000 μF reservoir capacity.
fig. 01 · power conditioning
PS 3000 HV Power supply
From T+A
PS 3000 HV is a supplementary mains unit for the A 3000 HV power amplifier and PA 3100 HV amplifier. It has 240,000 μF reservoir capacity, an 1800 W mains spec, a 17 x 46 x 46 cm chassis, and 38 kg weight.
Specifications
| Power Supply: Reservoir capacity | 240000 μF |
|---|---|
| Mains / Accessories / Dimensions: Mains | 110-120 V/60 Hz or 220-240 V/50 Hz / 1800 W |
| Mains / Accessories / Dimensions: Standby | < 0,5 W |
| Mains / Accessories / Dimensions: Optional Accessories | Power Three HD (Carbon) | Power Bar | HV-Individual finish (Individual colours on request)| IP control |
| Mains / Accessories / Dimensions: Dimensions (H x W x D) | 17 x 46 x 46 cm |
| Mains / Accessories / Dimensions: Weight | 38 kg |
| Mains / Accessories / Dimensions: Finishes | Case: silver laquer 47 or titanium laquer 64Heat sink: black 42 |
| Power output | more than 500 Watts of power into 4 Ohms |
