Unison Research · Integrated Amplifiers
Simply Italy Black Edition
Simply Italy Black Edition is a compact valve amplifier with KT77 output valves, electronic polarization, and USB, S/PDIF, and Toslink inputs.
fig. 01 · integrated amplifiers
Simply Italy Black Edition
6 photographs · 5 shown
From Unison Research
Simply Italy Black Edition updates the Simply Italy circuit with electronic valve polarization, a redesigned 5-section output transformer, and revised signal and power management. It uses ECC82 signal valves and KT77 output valves, with line inputs plus USB, S/PDIF, and Toslink for mixed analog and digital systems.
Specifications
| Output power | 10W |
|---|---|
| Bandwidth (-1dB) | 15Hz - 50kHz |
| Signal valves | 2 x ECC82 Gold Lion |
| Output power valves | 2 x KT77 Gold Lion |
| Polarization | electronically controlled pure Class A in ultralinear configuration with tap at 43% (power valves) |
| Inputs | 3 line RCA, 1 USB, 1 SPDIF, 1 Toslink |
| Bandwidth (-1dB) (2) | 15Hz - 50kHz |
| Outputs | 1 subwoofer RCA (stereo) |
| Feedback | selectable between 4dB and 3dB |
| Dimensions | 26 x 40 x 18 cm - 10 x 15.5 x 7.5 inches |
| Weight | 15Kg |
| Product type | valve integrated amplifier |
