Velodyne · Subwoofers
Deep Blue
Powered subwoofer series with front-firing drivers and a closed MDF cabinet.
fig. 01 · subwoofers
Deep Blue
From Velodyne
Deep Blue is a Velodyne powered subwoofer series built around front-firing drivers in a closed MDF cabinet. The saved specs list RCA/LFE and high-level inputs, 0-180-degree phase control, a 50-180Hz low-pass crossover, and black finish.
Specifications
| Driver | 15" forward firing |
|---|---|
| Amplifier | 1000 watts dynamic 450 watts RMS power |
| Frequency response | 13 - 200 Hz 23 - 120 Hz |
| Low-pass crossover | 50 Hz to 180 Hz (12 dB/Octave) |
| Phase | 0 to 180 degrees |
| Cabinet | MDF Closed Box with 52mm / 2" front Baffle |
| Magnet structure | Dual ferrite magnet motor |
| Woofer | 15" high excursion double vented basket driver with PP inforced Membrane |
| Voice coil | Four Layer 3" / 75mm Voicecoil |
| Input | GoldPlated Line in Stereo RCA, LFE in, Nickel Plated Highlevel |
| Output | Gold plated LFE /RCA |
| Power selector | Off / Auto / On |
| Finishes | Black |
| Dimensions | 42,5 x 44,5 x 48,8 cm |
| Weight | 23 kg |
| Shipping weight | 25,5 kg |
| Product type | powered subwoofer series |
| Series | Deep Blue |
