Velodyne · Subwoofers
VI-Q Series
Sealed subwoofer series with iWoofer app control.
fig. 01 · subwoofers
VI-Q Series
From Velodyne
VI-Q Series is a Velodyne sealed subwoofer line with iWoofer app control for room adjustment, a 25-band parametric equalizer, and presets. The saved specs list a front-firing driver, RCA, XLR, and high-level inputs, and 650W RMS amplification for the captured model.
Specifications
| Driver | 15" front firing driver |
|---|---|
| Amplifier | 1200 watt dynamic 650-watt RMS |
| Overall Frequency Response: (± 3 dB) | 23Hz - 180 Hz |
| Overall Frequency Response: (± 10 dB) | 18Hz - 220 Hz |
| Low-pass crossover | 50 Hz to 180 Hz (12 dB/Octave) |
| Phase | 0 / 180 degrees |
| Cabinet | 22mm HDF 50mm front |
| Magnet structure | Dual ferrite magnet motor |
| Woofer | 15" high excursion triple vented basket driver with carbon fiber Membrane and convex cone |
| Voice coil | Four Layer 3" / 76mm voice coil |
| Input | Gold plated Stereo/LFE RCA, Nickel plated XLR and High level in |
| Output | Gold plated Stereo/LFE RCA, Nickel plated XLR |
| Power selector | Off / Auto / On |
| Finishes | Flat mat black / Flat mat white |
| Dimensions | 48cm x 48cm x 56 cm |
| Weight | 32 kg |
| Shipping weight | 36 kg |
| Product type | sealed subwoofer series |
| Series | VI-Q |
